Circuit Continuity Tester Model CT-01
Features
The tester is supplied in a protective case, which can be worn on a belt or slung round the neck. The Continuity Tester is SABS approved as intrinsically safe and DME approved for use in fiery mines.
Certificates of approval DME no. CT1, CIE No. CT1.
Operation
The instrument employs a light emitting diode to confirm continuity in electric blasting circuits of up to 750Ω resistance.
It can be used for testing electric detonators at the working face, but permission to do so must first be obtained from the DMR and all MHSA regulations must be adhered to.
The unit is powered by 2xAA 1.5V Alkaline batteries and is capable of 1 million tests.
Notice and Maintenance
Note: There are no replaceable parts for this unit; therefore, it must be disposed if it becomes faulty.
SPECIFICATIONS
Warning and Disclaimer
The information and recommendations in this document are provided for reference purposes only and should not be construed as advice to cover every application of the product or variation of conditions under which the product may be used.
